    FC UPC Single Mode Fiber Jumpers , 3m Yellow Fiber Patch Cord For LAN CATV

    FC UPC Polish Singlemode Fiber Optical Jumper 3m Yellow Fiber Optical Patch Cord


    Description of Fiber Optic Patch Cord

    Fiber Optic Patch Cord a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles.


    Features:

    --- Good durability
    --- Good exchangeability
    --- High temperature stability
    --- Low insertion loss and back reflection loss
    --- Superior Quality Standard PC/UPC/APC Polishing
    --- Standard: Telcordia GR-326-CORE, TIA/EIA and IEC

    Application

    1. LAN, WAN and Metro Networks

    2. FTTH project & FTTX Deployments

    3. CATV System

    4. GPON, EPON

    5. Fiber Optic Test Equipment

    6. Data-base Transmit Broadband Net

    Specification:


    TypeStandard,Master
    StyleLC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC
    Fiber

    Singlemode/Multimode
    50/125, 62.5/125 (Multimode) OM2&OM1
    50/125, 10G (Multimode) OM3

    Cable

    Simplex, Duplex
    Φ3.0mm, Φ2.0mm, Φ0.9mm
    PVC or LSZH

    Polishing MannerUPC,SPC,APC (8°& 6°)
    Insertion Loss

    ≤ 0.1dB (For Singlemode Master)
    ≤ 0.25dB (For Singlemode Standard)
    ≤ 0.25dB (For Multimode)
    Tested by JDS RM 3750

    Return Loss

    (Singlemode)

    UPC ≥ 50dB
    SPC ≥ 55dB
    APC ≥ 60dB (typ.65dB)
    Tested by JDS RM3750

    Repeatability±0.1dB
    Operating temperature-400C to 850C

    Geometry Requirement

    ( Singlemode)

    Ferrule Endface Radius
    7mm ≤ R ≤ 12mm (For APC)
    10mm ≤ R ≤ 25mm (For Standard)
    Apex Offset ≤ 30 μm (For Master)
    Apex Offset ≤ 50 μm (For Standard)
    Undercut -50nm ≤ U ≤ 50nm
    Tested by DORC ZX-1

    Ordering options

    1) Connector type: FC, SC, LC, ST
    2) Ferrule End-face: PC, UPC, APC
    3) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
    4) Cable Quantity: Simplex, Duplex
    5) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
    6) Cable Length: 1, 2, 3 meter or customized
    7) Cable type: PVC, LSZH.
