Brand Name : | SLR or OEM |
Model Number : | FIBER PATCH CORD |
Certification : | CE ROHS |
Price : | Negotiable |
Payment Terms : | T/T, L/C, Western Union, MoneyGram |
Supply Ability : | 3000PCS/DAY |
Delivery Time : | 2Weeks after payment |
LC UPC / LC UPC MM FIBER OPTIC PATCH CABLE LC 1M 0.9MM / 2.0MM /
3.0MM
The fiber optic patch cord mainly used on patch panel or for the
connection between outlets and terminal equipment.It also widely
used for high bit rate data transmission,telecommunications,testing
instruments,active device terminations,LAN/WAN and FTTX.
LC connector is the samll form factor of SC square connectors.
Features:
1: Small size design
2: Push-pull
3: With High quality ziconia ferrules
4:ROHS compliant
5: PVC, LSZH, Riser Level jacket aviable
Applications:
---Telecom Net
---Local Ring Net
---Optical Fiber Sensor
---Optical Fiber Test Equipment
---Optical Fiber Communication System
---FTTH,LAN,PON & Optical CATV.
Ordering options:
1) Connector type: FC, SC, LC, ST
2) Ferrule End-face: PC, UPC, APC
3) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or
62.5/125um)
4) Fiber Count: Simplex, Duplex, or As order
5) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm, or as order
6) Length: 1, 2, 3 meter or customized
7) Jacket type: PVC, LSZH.Riser
Type | Standard,Master |
Style | LC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC |
Fiber | Singlemode/Multimode |
Cable | Simplex, Duplex |
Polishing Manner | UPC,SPC,APC (8°& 6°) |
Insertion Loss | ≤ 0.1dB (For Singlemode Master) |
Return Loss (Singlemode) | UPC ≥ 50dB |
Repeatability | ±0.1dB |
Operating temperature | -400C to 850C |
Geometry Requirement ( Singlemode) | Ferrule Endface Radius |
Type | Fiber Core | Cable Type | Cable OD | Cable Material | Cable Color | Connector (A End -B End) | Patchcord Length |
PT=Patchcord | S1=G652D | 01=simplex | 01=OD 0.9mm | 1=PVC(R) | 01=Blue 02=Orange | 01=SC 02=FC 03=ST | 005=0.5m |
PY=Pigtail | S2= G657A1 | 02=Duplex | 02=OD 2.0mm | 2=PVC(P) | 03=Green 04=Brown | 04=LC 05= E2000 | 010=1.0m |
M1=50/125 | 03=Armoured | 03=OD 3.0mm | 2=LSZH | 05=Slate 06=White | 06=SC/APC (Cone Type) | 020=2m | |
M2=62.5/125 | 04=Distribution | XX=other | 07=Red 08=Black | 07= SC/APC (Step Type) | 025=2.5m | ||
M3=OM3 | 05=Ribbon | 09=Yellow 10=Violet | 08= FC/APC (Cone Type ) | XXX=other | |||
M4=OM4 | 06=breakout | 11=Rose 12=Aqua | 09= FC/APC (Step Type) | ||||
XX=other | XX=other | 13=12Color XX=other | 10=LC/APC 11=E2000/APC | ||||
12=MTRJ 13=MPO/PC | |||||||
14=MPO/APC 15=D4 | |||||||
16=DIN 17=LX5 18=FDDI | |||||||
00=None XX=other |
![]() |
